Technical Chart

• HP/KW
  1 HP / 0.75 KW
  1 HP / 0.75 KW
  1 HP / 0.75 KW
  1 HP / 0.75 KW
  2 HP / 1.5 KW
  2 HP / 1.5 KW
  3 HP / 2.2 KW
  3 HP / 2.2 KW
  5 HP / 3.7 KW
• STAGE
  13
  14
  14
  14
  12
  25
  15
  25
  30
• VOLTAGE
  80 V
  110 V
  160 V
  220 V
  1700 V
  1700 V
  2700 V
  2700 V
  4400 V
• MECHANICAL WATT
  850 W
  850 W
  950 W
  1700 W
  1700 W
  2700 W
  2700 W
• DISCHARGE OUTLET (INCH)
  1.25 ‘’
  1.25 ‘’
  1.25 ‘’
  1.25 ‘’
  1.5 ‘’
  1.25 ‘’
  1.5 ‘’
  1.5 ‘’
  1.5 ‘’
• HEAD (IN METERS)
  60 METER
  55 METER
  50 METER
  70 METER
  30 METER
  50 METER
  70 METER
  50 METER
  90 METER
• DISCHARGE IN LPM
  30 LPM
  35 LPM
  40 LPM
  25 LPM
  120 LPM
  30 LPM
  120 LPM
  60 LPM
  90 LPM
• SHUT OFF HEAD
  75 METER
  78 METER
  80 METER
  90 METER
  50 METER
  110 METER
  80 METER
  120 METER
  130 METER
• OUTER DIA
  95 MM
  95 MM
  95 MM
  95 MM
  95 MM
  95 MM
  95 MM
  95 MM
  95 MM
• OVERALL EFFICIENCY
  30.00%
  30.00%
  30.00%
  60.00%
  30.00%
  30.00%
  30.00%
  30.00%
  30.00%
• MAXIMUM AMP
  7.0 A
  6.0 A
  4.0 A
  7.0 A
  8.0 A
  8.0 A
  8.0 A
  8.0 A
  8.0 A
• SIZE OF CABLE
  1 * 3 * 2.5 SQ.MM
  1 * 3 * 2.5 SQ.MM
  1 * 3 * 2.5 SQ.MM
  1 * 3 * 2.5 SQ.MM
  1 * 3 * 2.5 SQ.MM
  1 * 3 * 2.5 SQ.MM
  1 * 3 * 2.5 SQ.MM
  1 * 3 * 4 SQ.MM
  1 * 3 * 4 SQ.MM
• RPM
  2800
  2800
  2800
  2800
  2800
  2800
  2800
  2800
  2800
